Product Description:

PowderPro M1 is a powder characteristics tester to measure repose angle, collapse angle and other powder characteristics. PowderPro M1 is the manual version of the automatic PowderPro A1.  It can perform the same analysis of PowderPro A1 through a manual process. PowderPro M1 is a good choice for small laboratories and academia.

Test Items: angle of repose, angle of fall, angle of difference, angle of spatula, angle of slide, voidage, dispersibility, tapped density, bulk density, hall flow, compressibility, cohesiveness, uniformity, flowability index, floodability index.

Features:
- Test methods for angle of repose, non-metallic bulk density, tap density, the degree of compression according to GB / T 16913-2008-4.5 method.
- Metal powder and non-metallic powder's tap density according to GB / T 5162-2006 / ISO3953: 1993
-Degree of dispersion, flat angle, uniformity ratio and degree of agglutination are essential to calculating the Carl fluidity index according to US standards ASTMD6393-08
-Test for tap density meet standards 07/2010: 20934E of the European Pharmacopoeia EP7.0 and USP 616.

Parameter:
Angle Range:0-90°
Angle Testing Method:Protractor method. Testing repose angle, collapse angle, and plate angle by protractor.
Repeatability Error:≤5%
Tap Density Frequency:250 times/min
Tap Density Amplitude:3mm or 14mm
Standard:
       Chinese Standard:
       GB/T16913-2008   4.5
       GB/T1479.1-2011
       GB/T5162-2006
       American Standard:  ASTM D6393-14
       United States Pharmacopeia: USP32-NF27<616>
       European Pharmacopeia: EP7.0  07/2010:20934
Voltage:AC220V , 50/60Hz ,200W
Volume , Weight: 580x350x650 mm , 37 kg

Packing:

1. Using the thickened cartons;
2. Thick foam board and buffer air bags are used inside of the carton to protect the instrument.
3. Using the wooden cases made by the plywood outside the carton to further protect the instruments;
4. After the product is packaged, we will carry out the package drop test to further ensure the safety of the instrument for long distance transportation.

Our Service:

Within One Year Warranty:
1.Free provide spare parts.
2.Send engineer to maintain (User pay the round-trip tickets).
3.Send back to maintain (Both sides share the half freight).
Beyond One Year:
1.Should breakdown result from misuse or out of warranty, two sides negotiate the site & method of maintenance. Buyer pays the expense.
2.Consumable spare parts and articles etc. are not guaranteed.

About Us:

    Dandong Bettersize Instruments Ltd was founded in 1995 and is the largest manufacturer of particle size instruments in China. Currently, there are nearly 150 employees. Having achieved 43 patents (including 15 invention patents); 16 software Copyrights and one trademark. Overseas agents: the USA, Germany, South Korea, Russia, India, Brazil, Argentina, Vietnam, the Czech republic, Mexico, Poland, Pakistan, Malaysia, Indonesia, Turkey, Italy, Taiwan, Hong Kong... Domestic users are distributed in 32 provinces and cities across China and International users are located in 50 countries on four continents, with a total of more than 10000 users, and the quantity is still increasing greatly.
   Sincerely hope to have the chance to have a good cooperation with all the end users and distributors ! Dandong Bettersize Instruments Ltd welcomes your visiting !
