Air Sampler portable Sampler
planktonic air sampler
www.nordachina.com/en
Portable air sampler / Planktonic Bacteria Air Sampler/Bacteria Sampler/ portable Sampler
Suzhou Norda Cleaing Tech Co.,ltd Norda Brand
Model: PBS-D( economical ), PBS-E ( ecnomical ) ,PBS-100( high )
Advantage :More Portable, More popular Stable Performance, Easily Operate,
Low Cost, More Light and Small
Features :
1. Fan (Switzerland imported) ,high stability, to ensure that the sampling rate is less volatile.
2. Flow rate deviation is less than 4% or 2.5%
3. The upgrading from the old one,like older model JYQ-IV,FSC-IV,and FKC.
4. Stainless steel Sampling head (SUS316), with high accuracy machining, up/down diameters of microholeare same to optimize air flow state and actualize best bacteria capture effect;
Corrosion resistance, oxidation resistance,more easy to Disinfect,
Aluminum sampling head(optioanl),more cheaper
(PBS-D)
5. Smallest volume and lightest weight in the same kind of domestic products.
6. Optional compressed air sampling gatherer for measuring plank-tonic bacterial compressed air. (Optional )
7. Long battery life (5-7h)
8. Convenient sampling and easy to change culture dish (Φ90mm×15mm)
9. Optional sampling bracket.(Optional )
Instruction
PBS air sampler is a kind of high effective air biological sampler. It is designed according to the principle of multi-jet holes particle impact and isokinetic sampling. And it gets the consistence of animalcule more accurately. When sampling, airborne particles will impact on agar surface of substrate utensil through tiny hole; after incubation of the agar plate, colonies can be counted and identified.
PBS-D is with superior production process and perfect details handling in the same kind of domestic products and with a economic price,convenient operation,long life and adjustable flow.It can be matched two kinds of sampling head, one is the aluminum sampling head,another is stainless steel sampling head with high perform
| Model : |
PBS series |
| Version |
English and Chinese |
| Flow rate |
100L/min ( deviation<4% or2.5%) |
| Battery recharge |
4h |
| Battery life |
Continually work for 5-7h |
| Body material |
Anodized aluminum |
| Sampling head meterial |
Stainless steel (SUS316) or aluminum alloy (optional) |
| Dim.(mm) |
￠120*160 |
| Weight |
1.8KG(SUS 316 sampling head);1.5KG(aluminum ally sampling head) |
| Standard preset volume |
100L,500L,1000L |
| Sampling volume setting |
50-12000L (set freely) |
| Standard configuration |
instrument, recharger, case, operation manual, test report, |
| Optinal |
SUS316 / aluminum alloy sampling head / compressed air gatherer,bracket |
