LCD Display

Large digital display is easy to monitor all the safety parameters at a glance and ergonomically

sized control panel improves user interface.

Work Zone

Work zone, made of 304 stainless steel, is surrounded by negative pressure.

Remote Control

All functions can be realized with it, making the operation much easier and more convenient.

UV lamp

Emission of 253.7 nanometers for most efficient decontamination.

Front Window

Two-layer laminated toughened glass>5mm, anti UV

Footmaster caster

Universal caster with brake and leveling feet.

Adjust front window height by foot during experiment, to avoid airflow turbulence caused by arm

movement.

Foot Switch

Adjust front window height by foot during experiment, to avoid airflow turbulence caused by arm

movement.

Advantage:

1. Motorized Front Window.

2. Time Reserve Function.

3. HEPA Filter life and UV Life indicator.

4. Automatic air speed adjustable with filter block.

5. Work area surrounded by negative pressure, it can ensure maximum safety in work area.

6. Audio and visual alarm (Filter replacement, Window over height, abnormal Air flow velocity etc).

7. Most accessories are standard. No need to pay more, save your money.

8. Remote Control. All functions can be realized with it, making the operation much easier and more convenient.

9. Foot Switch. Adjust front window height by foot during experiment, to avoid airflow turbulence caused by arm movement.

10. Interlock Function: UV lamp and front window; UV lamp and blower, fluorescent lamp; Blower and front window.

Specification:

Model	BSC-1100IIA2-X	BSC-1300IIA2-X		BSC-1500IIA2-X	BSC-1800IIA2-X		BSC-2000IIA2-X
Internal Size (WDH)	940* 600*660 mm	1100600660 mm		1350600650mm	1710600660 mm		1800600660mm
External Size (WDH)	11007502250mm	13008502200mm		15008402280mm	18707502290mm		19508002305mm
Tested Opening	Safety Height ≤ 200 mm
Inflow Velocity	0.53±0.025 m/s
Max Opening	400mm
Downflow Velocity	0.33±0.025 m/s
HEPA Filter	Two, 99.999% efficient at 0.3 um. Filter life indicator.
Front Window	Motorized. Two-layer laminated toughened glass ≥ 5mm. Anti UV.
Noise	EN12469 ≤ 58 dB / NSF49 ≤ 61 dB
UV Lamp	30W*1	18W* 1		40W* 1	40W*2		40W* 1
	UV timer, UV life indicator, emission of 253.7 nanometers for most efficient decontamination.
Fluorescent Lamp	21W*2	21W*2		28W*2	40W*2		40W*2
Illumination	≥1000Lux
Consumption	760W	1060W		1300W	1350W		1700W
Waterproof Sockets	Two, total load of two sockets: 500W
Display	LCD display: exhaust filter and downflow filter pressure, filter and UV lamp working time, inflow and downflow velocity, filter life, humidity and temperature, system working time etc.
Control System	Microprocessor
Airflow System	70% air recirculation, 30% air exhaust
Visual and audio alarm	Filter replacement, window over height, abnormal air flow velocity.
Material	Work Zone: 304 stainless steel
	Main Body: Cold-rolled steel with anti-bacteria powder coating.
Work Surface Height	750mm		caster			Universal caster with brake and leveling feet.
Power Supply	110/220V±10%, 60/50Hz
Standard Accessory	Fluorescent lamp,UV lamp2 ,Base stand, Remote control, Foot switch, Drain valve, Waterproof sockets2
Optional Accessory	Water and gas tap
Gross Weight	255kg	305kg		350kg	390kg		420kg
Package Size (WDH)mm	1250× 1050× 1870	145010501870		164010401860	201010501960		209010501860
