Main functions and characteristics

The chassis is made of sanitary ABS material, high strength all engineering plastic chassis, ergonomic design, beautiful appearance, prevent corrosion and rust, ensure collective cleanliness, in accordance with GLP specifications.

Unique 4 door design, easy to observe and easy to get water.

Pretreatment, RO membrane and other consumables are clamped, and the filter element can be loaded and unloaded by left and right rotation. The filter element can be safely and conveniently replaced without professional training.

Powerful pretreatment components, including a variety of different role of filter elements, effectively remove particles from tap water, free chlorine and colloids, protect the RO membrane and extend life

The super purification component and control part adopt independent modular structure, and the system maintenance is more convenient.

The pipe joints are NSF certified to minimize the TOC precipitation and ensure the highest pure water quality.

Automatic pressure sensor and microcomputer control work to achieve automatic manufacture of pure water, water shortage stop alarm, automatic shutdown

Built-in independent Mini TOC total organic carbon online measurement module, equipped with independent color display screen, real-time monitoring of ultra-pure water TOC (selection)

Ultra pure water circulation function can be freely activated and closed to ensure low bacterial contamination level of the system.

The brand new super purification component of the top resin ensures the production of water up to 18.2 M -cm and the minimum TOC precipitation.

High-energy ultra-long life 254-185 dual-wavelength UV lamp, effective sterilization, reduce TOC, enhance the scope of application of the system

MWCO5000DUF ultrafiltration module can effectively remove endotoxin from heat source, which can be used for precise cell culture and IVF.

Double terminal sterilization filter, accuracy: (0.45+0.1) um, ensure terminal water absolutely sterile.

WP series ultra water purification system(Inlet: Tap water)

Specification			Standard	Eliminating endotoxin	Low TOC	Comprehensive
Model		standard	WP-15L	WP-15L UF	WP-15L UV	WP-15L UVF
		Large flow	WP-30L	WP-30L UF	WP-30L UV	WP-30L UVF
Flow procedure			PF+AC+RO+DI +DMF	PF+AC+RO+DI+UF+DMF	PF+AC+RO+UV+DI+DMF	PF+AC+RO+UV+DI+UF+DMF
Inlet water requirement			Tap water：TDS<200，5-40℃，1.0～3.5Kg/cm²，（when TDS＞200,suggest to match outside softening tube)
Water Quality	Desalination		Nearly 100%
	Resistivity		18.2 MΩ-cm @25℃
	TOC ppb		<10ppb		<3ppb
	Endotoxin		——	<0.001 Eu/ml	——	<0.001 Eu/ml
	Virus cfu/ml		< 1cfu/ml
	Particle ＞0.22μm		< 1/ml
Water outlet			2: RO water ；Ultra pure water
Digital water monitor			Automatic control LED display screen for water +LCD with back light
Inlet water requirement			Tap water：TDS<200，5-40℃，1.0～3.5Kg/cm²
Output（25℃）			15 L/H* 30 L/H*
Instantaneous output L/min			1.5 L/min (with pressure tank) (Less output with UF/UV cartridge)
External dimension / Weight			H×W×D: 59×50×45 cm/ about 20 kg
Powder			100-220V,50HZ/ standard 《75W. Large flow《150W

WP series ultra water purification system(Inlet: Distilled water)

Specification		Standard	Eliminating endotoxin	Low TOC	Comprehensive
Model	standard	WP-D 15L	WP-D 15L UF	WP-D 15L UV	WP-D 15L UVF
	Large flow	WP-D 30L	WP-D 30L UF	WP-D 30L UV	WP-D 30L UVF
Flow procedure		AC +DI +DMF	AC +DI+UF+DMF	AC +UV+DI+DMF	AC +UV+DI+UF+DMF
Inlet water		Ro water, distilled water, deionization water
Water Quality	Resistivity	18.2 MΩ-cm @25℃
	Heavy metal iron	<0.1ppb
	TOC ppb	<10ppb		<3ppb
	Endotoxin	——	<0.001Eu/ml	——	<0.001Eu/ml
	Virus cfu/ml	< 1cfu/ml
	Particle ＞0.22μm	< 1/ml
Instantaneous output L/min		1.5 L/min (with pressure tank) (Less output with UF/UV cartridge)
Water outlet		2: highpurity water ；Ultra pure water
Digital water monitor		Automatic control LED display screen for water +LCD with back light
Output（25℃）		1.5－2.0 L/min (with pressure tank) (Less output with UF/UV cartridge)
External dimension / Weight		H×W×D: 59×50×45 cm/ about 20 kg
