Application:
Low Temperature Thermostatic Bath is widely used in the fields of biological engineering, medicine, food, chemical industry, chemical analysis, petroleum, etc, providing a constant high precise, controlled, temperature homogeneours place for users. Its temperature is controlled by microprocessor with PID regulator. It has such advantages as fastness in temperature rising and dropping, high precision in controlling temperature.
Features:
DC series of low-temperature thermostat bath main performance Description:
1. whole sealing refrigeration compressor, refrigeration system is overheating, over-current protection device of multiple
2. Circulating pump can be constant temperature liquid tank outside the guidelines, a second constant temperature field.
3. Tank of cold liquid can be introduced outside, cooler outside the experimental container, but also in the slot directly to low-temperature, constant temperature experiment
4. Using XMT analog and digital PID control system, temperature digital display.
5. Liner, countertops are stainless steel, clean, beautiful and corrosion resistance. DCW series horizontal.
Specification:
|
Model |
Temp.Range
(°C) |
Temp.
Fluctuating (°C) |
Working Solt Size
(mm3) |
Solt depth
(mm) |
Cyc. Pump Flux. (L/min) |
Working Solt Opening (mm2) |
|
DC-0506 |
-5~100 |
±0. 05
|
250×200×150 |
150 |
4 |
180×140 |
|
DC-0510 |
250×200×200 |
200 |
4 |
180×140 |
|
DC-1015 |
280×250×220 |
220 |
4 |
235×160 |
|
DC-1020 |
280×250×280 |
280 |
4 |
235×160 |
|
DC-0530 |
400×325×230 |
230 |
13 |
310×280 |
|
DC-1006 |
-10~100 |
±0. 05
|
250×200×150 |
150 |
4 |
180×140 |
|
DC-1010 |
250×200×200 |
200 |
4 |
180×140 |
|
DC-1030 |
400×325×230 |
230 |
13 |
310×280 |
|
DC-2006 |
-20~100 |
±0. 05
|
250×200×150 |
150 |
4 |
180×140 |
|
DC-2010 |
250×200×200 |
200 |
4 |
180×140 |
|
DC-2015 |
300×250×200 |
200 |
4 |
235×160 |
|
DC-2020 |
280×250×280 |
280 |
4 |
235×160 |
|
DC-2030 |
400×325×230 |
230 |
13 |
310×280 |
|
DC-3005A |
-30~100 |
±0.1
|
250×200×120 |
120 |
4 |
180×140 |
|
DC-3006 |
250×200×150 |
150 |
4 |
180×140 |
|
DC-3010 |
250×200×200 |
200 |
4 |
180×140 |
|
DC-3015 |
300×250×200 |
200 |
4 |
235×160 |
|
DC-3020 |
280×250×280 |
280 |
4 |
235×160 |
|
DC-3030 |
400×325×230 |
230 |
13 |
310×280 |
|
DC-4006 |
-40~100 |
±0.1
|
250×200×130 |
130 |
4 |
180×140 |
|
DC-4010A |
310×210×150 |
150 |
4 |
185×180 |
|
DC-4010B |
250×200×200 |
200 |
4 |
180×140 |
|
DC-4015 |
300×250×200 |
200 |
4 |
235×160 |
|
DCW-0506 |
-6~100 |
±0. 05
|
250×200×150 |
150 |
6 |
180×140 |
|
DCW-1015 |
-10~100 |
280×250×220 |
220 |
4 |
235×160 |
|
DCW-2008 |
-20~100 |
280×250×140 |
140 |
4 |
235×160 |
|
DCW-3506 |
-35~100 |
±0.1
|
250×200×150 |
150 |
4 |
180×140 |
|
DCW-3510 |
250×200×200 |
200 |
4 |
180×140 |
|
DCW-4006 |
-40~100 |
250×200×130 |
130 |
6 |
180×140 |
