BIOBASE PCR Thermal Cycler,JINAN BIOBASE BIOTECH CO.,LTD_specification/price/image

BIOBASE PCR Thermal Cycler

Product Description

BK-EO Features

1. Intuitive interfaces

2. Superior performance

3. Multiple temperature control modes

4. Gradient function thermal cycler

5. Smart block

6. Three modes of operation for your choice

BK-TC Features

1. Advanced thermoelectric cooling technology and creative TAS technology

2. Higher precision of temperature control

3. Faster heating and cooling speed

4. Better block temperature uniformity

5. Smaller instrument dimension

6. More silent operation environment

Model	BK-EO	BK-TC
Sample capacity	96-PCR plate(full-skirted) 960.2ml tubes 128-strip
Cooling technology	Peltier-based
Display	LCD display and touch creen(5.7 inch)	6.5 inch,262 144 color LCD display and touch screen
Temp. Range	4.0-99.9℃
Heating speed of ramping	Up to 4℃/sec
Cooling speed of ramping	Up to 4℃/sec
Temp. uniformity	≤±0.3℃	≤±0.2℃
Temp. accuracy	≤±0.1℃(50℃), ≤±0.2℃ (≥90℃)
Temp. control modes	BLOCK or TUBE
Ramping range adjustable	0.1℃-4℃
Memory	≥250 typical programs onboard, unlimited with USB flash drive expansion
Max. No. of cycle	99. Suitable for nested PCR
Time up/down	0-9 min 59s, suitable for long PCR
Temp. up/down	0-9.9℃,suitable for touchdown PCR
Auto pause/power protection	YES
Soak function	Yes
Gradient range of temp. difference	1-30℃
Gradient range	30-99.9℃
Hot-lid Temp. range	Room temperature +5℃-110℃(default 105℃)
Height of hot-lid	Automatic Adjusted
Auto shut-off function of hot lid	While block temperature is lower than set temperature or program ends, the hot-lid will be automatically closed
Communication Interface	USB	LAN
Power supply	100-240V, 50/60Hz, 600W
Dimension	335260270mm	345260270mm
Packing size(LWH)	495410395mm	495410395mm
Gross weight	10.5KG	12,5KG
Certificates	Ferrotec Peltier/CE/RoHS2.0
