Application
Widely use in laboratory, food, chemical, pharmaceutical, environmental use.
Product Composition and Flow Rates
|
Drive
|
Pump Head
|
Tubing
|
Flow Rates (mL/min)
|
|
BT300N
|
YZ1515x
|
13# 14# 19# 16# 25# 17# 18#
|
0.035~1140
|
|
YZ2515x
|
15# 24#
|
0.085~870
|
|
N*YZ1515x
|
13# 14# 19# 16# 25# 17# 18#
|
0.035~1140 per channel
|
|
N*YZ2515x
|
15# 24#
|
0.085~870 per channel
|
|
DG-N(6 rollers)
|
0.5×0.8,1×1,
2×1, 2.4×0.8
|
0.002~45 per channel
|
|
DG-N(10 rollers)
|
0.05~35 per channel
|
|
SN25
|
24#
|
0.17~750
|
Features
1. The features of attractive appearance, compact structure and human design make it become the prior choice product of the laboratory application.
2. Touch key has the characteristics of comfortable feel, attractive appearance and long service life. Finish the operation through touching lightly the key by finger with sound effect at the same time.
3. The key of full and empty help you to quickly dischagre the air from tubing and fill the liquid.
4. Unique function of sixty seconds test makes you no longer measure flow rate of one minute by watch. Lightly tap the key of sixty seconds test, peristaltic pump will work one minute under your set rotating speed.
5. Choose a lot of external control mode, 0-5V, 0-10V, 4-20ma speed, level signal control start and stop, change direction, and also communicating with PC through RS232 communication protocol.
The user can decide the eight different external control modes on the panel, is the best choice of supporting a variety of instruments.
6. Acceptable pump heads for YZ1515x, YZ2515x, SN25, DG-1, DG-2, DG-4, DG-6, DG-8, DG-12.
7. Dual CPU control, seperating the drive and control, quick operation speed, stable work and high precise transmission.
8. High torque and low power loss, connect many pump heads in series or install multichannel pump head for satisfying the different application situations.
9. Load-shedding memory function, storing the running parameters automatically in time. It is very safe and reliable.
10. It is not suitable for outdoor application.
Technical Specifications
|
Rotating speed
|
1-300rpm, reversible
|
|
Speed precision
|
0.1rpm
|
|
Speed control
|
Lightly touch membrane keypad for adjusting speed or full speed
|
|
Display
|
3-digit LED displays current rotating speed
|
|
External control
|
Start/stop and cw/ccw control: receiving level signal
|
|
Speed control: 0-5V, 0-10V, 4-20mA optional
|
|
RS232 serial communication, control start/stop, cw/ccw and speed
|
|
Power supply
|
AC 220V±10%, 50Hz/60Hz(standard)
AC 110V±10%, 50Hz/60Hz(optional)
|
|
Power consumption
|
<22W
|
|
Operating condition
|
Temperature 0 to 40 C° . Relative humidity < 80%
|
|
Drive dimensions (L×W×H)
|
180x130x190mm
|
|
Drive net weight
|
3.98Kg
|
|
Level of protection rating
|
IP 31
|
|
