Sugar centrifugals play a pivotal role in sugar production by facilitating the crucial step of separating sugar crystals from molasses after the crystallization process. This separation process is vital for achieving the desired purity, color, and granulation of the final sugar product. By effectively removing impurities and excess moisture, centrifugals ensure the production of high-quality refined sugar products that meet industry standards and consumer expectations.

Western States manufactures both batch and continuous centrifuges for processing all grades of sugar and sugar cane. Western States centrifuges are used in both the beet and cane sugar industries, as well as other non-sucrose applications such as the manufacturing of the sweeteners dextrose and fructose.

Batch centrifugals are a type of centrifuge used in various industries, including sugar production, for separating solids from liquids or for classifying particles based on density. In the context of sugar production, batch centrifugals are specifically designed for the separation of sugar crystals from mother liquor (molasses) after crystallization.

Continuous centrifuges are a type of centrifuge used in various industries, including sugar production, for separating solids from liquids or for classifying particles based on density. Continuous centrifuges are an integral part of modern sugar production, offering high efficiency, throughput, and continuous operation, which are essential for meeting the demands of large-scale industrial processing. Their automation features and consistent performance make them a preferred choice for many sugar refineries and processing plants worldwide.

Series and Parameters

No	Model	XJZ 1350-N	XJZ1400-N	XJZ1600-N	XJZ 1750-N
1	Dia of basket mm	1350	1400	1570	1600
2	Max.Speed mm	1450	1200	1100	1050
3	Max.load capacity kg	1100	1300	1750	2200
4	Working volume liter	797	870	1089	1370
5	G.force	1590	1007	1083	1048
6	Power of motor kw	90	110	200	250
7	Size mm	275618464466	250819005364	312022904920	319021904780
8	Weight kg	6200	8600	10000	12000

Structure:

Mainly includes machine housing and base, drum, screen, spindle, coupling, feeding system, probe device, washing system, mother liquid separation device, discharging system, gas control device, motor, frequency converter, PLC control system, etc.

Working principle.

When the basket rotates at high speed, it will produce a centrifugal force thousands of times greater than its own weight, so that the sugar paste on the basket wall is subjected to the centrifugal force, and the granulated sugar crystal are intercepted in the basket by the screen to form a filter layer,Under the action of centrifugal force, molasses will pass through the filter layer and screen, and finally flow out of the basket hole wall to complete the separation of crystal and mother liquor.The primary sugar paste separation can be divided into four stages: sugar layer formation stage, centrifugal molasses removal stage,molasses washing stage and drying(separating) stage.
