UC automatic sampler is an intelligent automatic sampler. The X, y, Z three-dimensional electronic driving actuator can sample at any position and with flexible and reliable high speed and high precision. The injection needle is directly inserted into the valve. The extremely low dead volume ensures the accuracy of injection.
Technical parameter table
Injection mode
X-Y-Z operation mode, vertical port electronic control six way injection valve
Repeated injection
Each sample bottle can be repeated 1-99 times
Repeatability
The relative standard deviation of typical peak area was less than 0.5% from 2ul injection volume
Sample injector size
250 or 500 UL
Cleaning times
1 ~ 99 times of user's choice, to ensure that the sample cross carry < 0.02%
Cleaning volume
0~200uL
Sample capacity
Different trays can be selected, with a maximum of 120 sample bottles
Method parameters
Including injection volume, repeat times, cleaning volume, cleaning times, start and stop time
display
LCD, 4.3 "true color
control
32-bit embedded microprocessor with ARM7 core
communication
RS232 can be controlled by PC software
Power Supply
Communication 220 ± 20V power rate 75W
environment condition
10 ~ 30 ℃, relative humidity 20 ~ 80%
External dimension
Length 455 width 455 height 260mm
