Model
|
FS-50B
|
FS-70B
|
Shaking Mode
|
Cyclotron Oscillation
|
Function
|
Amplitude
|
Ф20mm
|
Temp. Resolution
|
0.1℃
|
Temp. Motion
|
±0.1℃
|
Temp. Uniformity
|
±1℃
|
Temp. Range
|
RT+5~65℃
|
4~65℃
|
Rotary Speed
|
30~300rpm
|
30~300rpm
|
Rotary Speed Precision
|
±1rpm
|
Structure
|
Chamber Material
|
Mirror Stainless Steel
|
Outer Shell
|
ABS
|
Observation Window Material
|
Imported resin
|
Thermal Insulation Material
|
Polyurethane
|
Cooling System
|
No
|
Yes
|
Coolant
|
No
|
R134a
|
Heater
|
Stainless steel heating tube
|
Drive Mode
|
Three-axis level
|
Oscillating Plate
|
Spring Wire Rack
|
Air Circulation Mode
|
Horizontal convection
|
Power Rating
|
0.6kW
|
0.8kW
|
Controller
|
Temp. Control Mode
|
LCD PID intelligent control
|
Cyclotron Control Mode
|
Automatic changes of rotation direction
|
Setting Mode
|
Touch button setting
|
Temp. Display Mode
|
LCD display
|
Speed Display Mode
|
Timer
|
0~9999min
|
Operation Function
|
Fixed value operation、timing function、bidirectional automatic switchover、auto stop、quick stop start
|
Temperature Sensor
|
Pt100
|
Speed Sensor
|
Hoare
|
Gating System
|
Yes
|
Additional Function
|
Deviation correction, menu keys locked, power-off memory
|
Safety Device
|
over temperature alarm, menu locked, gating system ,power-off protection , plugging turn protection
|
Specification
|
Inner Chamber Size (W*L*H)(mm)
|
455*380*290
|
560*390*320
|
Exterior Size (W*L*H)(mm)
|
500*640*480
|
600*770*500
|
Packing Size (W*L*H)(mm)
|
550*690*530
|
940*780*655
|
Shelf Size(mm)
|
380*320
|
480*315
|
Max capacity of Shelf for single specification(ml/pc)
|
100ml*16/250*10/500*6
|
100ml*28/250*15/500*8/1000*6
|
Number of flask clamp as standard (ml/pc)
|
250*8
|
250*12
|
Inside Volume
|
50L
|
70L
|
Shelf Load Bearing
|
≤10kg/layer
|
≤15kg/layer
|
Shelf Layer
|
1
|
Power Supply (50/60Hz)Current Rating
|
AC220V/2.5A
|
AC220V/3.5A
|
NW/GW (kg)
|
25/35
|
65/85
|
