50l Chemistry Jacketed Glass Reactor Price
50l Chemistry Jacketed Glass Reactor Price
Place of Origin:
China
Model:
TOPT-50L
Price:
USD4000
Hits:
42
Updated:
11/12/2019
  • Product Detail
  • Company Profile

    50l Chemistry Jacketed Glass Reactor Price





    Product Description Of  50l Chemistry Jacketed Glass Reactor Price



    Double glass reactor main sealing parts pure PTFE material, guarantee absolute vacuum system. Double

    glass reactor double glass design, inner into reaction menstruum do stirring reaction, interlayer can pass

    different cold sources (cryoprotectants, hot water or hot oil) do cycle heating or cooling reaction.

    50l Chemistry Jacketed Glass Reactor Price



    Technology Parameters Of  50l Chemistry Jacketed Glass Reactor Price





    Technology

    parameters

    TOPT-50L

    TOPT-80L

    TOPT-100L

    Stir medium flange

    50

    50

    60

    Liquid material inflow

    34# 1L

    5L 24#

    5L  24#

    Condenser

    34#

    DN40 ball mouth

    DN40  ball mouth

    Temp. measure

    DN15

    DN15

    DN15

    Multi function valve

    DN25

    DN25

    DN25

    Solid  charging

    port

    DN80

    DN80

    DN80

    Stirring paddle

    16mm double layer three blade paddle type

    16mm three layer three blade paddle type

    16mm three layer three blade paddle type

    Reactor lid flange(mm

    265

    340

    340

    Inner diameter of reactor   body(mm)

    365

    410

    460

    External diameter(mm)

    410

    460

    500

    Reactor body   height(mm)

    850

    950

    950

    Power

    (w)

    140

    250

    250

    Rotate speed

    (rpm)

    50-600

    50-600

    50-600

    bio-equip.cn
    Toption Company professional Lab solution provider ,mainly manufacture for glass reactor, stainless steel reactor, photochemical reactor, rotary evaporator, short-path molecular distillation, labglassware, freeze dryer , spray dryer, ultrasonic cleaner, ultrasonic homogenizer, and also deal kinds of oven & Incubator, Centrifuge, Autoclave, Shaker, Stirrer, Freezer,Fume Hood, Laminar Flow Cabinet, etc.
