Direct-Pure UP UV Ultrapure Water System (2-Pass RO) produce Type I and more than Type III water directly from tap water in a single compact system. It is the ideal system for customers without pretreated water available.

Specifications:
Feed Water:
Tap Water with TDS<1000 ppm, 5-35 ℃, 1.0～3.5 kg/m²

Flow Rate: 15 L/h, 30 L/h for RO water
Up to 2.0 L/min for Type I water

Product Water Quality:
· Resistivity: 18.2 MΩ•cm@ 25 ℃
· TOC Level(Typical Values): ≤ 5 ppb*
· Particles (>0.22 µm): No particles (with an optional 0.2 μm final filter or a RephiBio filter)
· Microorganisms: < 0.01 cfu/ml (with an optional 0.2 μm final filter or a RephiBio filter)
· Pyrogen: < 0.001 Eu/ml (with a RephiBio filter)
· Water outlet: Ultrapure water＋RO pure water

Dimensions: Length×Depth×Height(cm): 32 X 50 X 48
* Depends on feed water quality

Features:
· Assembly Kit treats feed water and protects RO membranes from surface scale build-up, eliminates the need for softening and extends RO membrane life.
· Advanced 2-Pass reverse osmosis technology removes more than 99% of contaminations and ions from feed water.
· The patented RephiQuatro U Pack ultrapurification cartridge ensures minimal dead water volume and ion-free and organic–free product water that meets or exceeds, CLSI and CAP Type I water standards.
· Final purification is carried out by a 0.2 µm sterile filter to remove bacteria and particles above 0.2 µm size.
· High-precision resistivity meter with temperature compensation guarantees accurate resistivity of product water measurement.
· Built-in dual-wavelength UV lamp effectively removes a variety of trace organics from pure water.
· Advanced control system monitors unit performance and displays RO membrane performance, ultrapure water resistivity, reservoir level, cartridge status.

We can provide support documents to meet GMP, GLP, FDA and other validation protocols.

Applications:
Ultrapure Water
HPLC (High-Performance Liquid Chromatography) flowing preparation;
Reagent blank solution preparation;
Dilution for GC, HPLC, AA, ICP-MS and other analytic technique samples;
The buffer solution using for mammal cell culture and culture medium preparation;
Molecular biology reagent preparation etc.

RO Pure Water
Cleaner for rinsing glassware;
Water baths;
Autoclave;
Laboratory animal raising etc.
