Character
●Single-chip microcomputer control, LCD Screen (128*64 Dots)
●Large LCD display can display multiple sets of data
●Huge memory space to store multiple sets of data and curves
●Auto zero,100% adjustment function
●Wavelength automatic adjustment
●Wrap lights, automatic filter change , large sample pool (0.5mm ~ 100mm)
●Standard samples having a maximum ten-point standard curve measurement functions built
●Direct input by K, B factor for quantitative measurement standard curve
●Can be directly input and the corresponding standard concentration values establish a standard curve for quantitative measurement
●Adjustable electric saving standard curve parameter measuring set, can save a plurality of standard curve
●Can be edited at any time of the standard curve , user-friendly
●General Parallel printer interface with or slightly beat interfaces can print the title bar, the measurement data , curve parameters , the standard curve and the curve sample points
●With USB interface
●PC control can be achieved through more accurate and flexible measurement requirements ( standard )
Software features
●Wavelength Scan: the measured object can be 190nm-1100nm full band spectrum scan , can also be segmented scan
●Kinetic tests: the time of the measured object scanning , timely detection of changes in concentration caused by changes in absorbance
●Quantitative measurement: by establishing a standard curve , the concentration can be measured in the analysis was
●Multi- wavelength testing : set a plurality of wavelengths simultaneously , the measured absorbance of a plurality of wavelengths in the test
●DNA / protein test: the test formula purity of nucleic acid and protein concentration analysis of DNA / protein
Technical Specifications
|
Wavelength Range |
190～1100nm |
|
Band Width |
4nm |
|
Wavelength Accuracy |
±0.5nm |
|
Wavelength Repeatability |
≤0.2nm |
|
Photometric Accuracy |
±0.5% τ |
|
Photometric Repeatability |
0.2% τ |
|
Stray Light |
≤0.05% τ (220nm NaI，340nm NaNO2) |
|
Stability |
0.001A/h@500nm |
|
Photometric Mode |
T,A,C,E |
|
Wavelength Setting |
Automatic |
|
Photometric Display Range |
-0.3～3A |
|
Display Mode |
LCD Screen (128*64 Dots) |
|
Detector |
Import Silicon Photodiode |
|
Light Source |
Import Deuterium Lamp & Tungsten Halogen Lamp |
|
Power Requirement |
AC 220V/50Hz 110V/60Hz |
|
Power |
120W |
|
Dimensions(W*D*H) |
480×350×220mm |
|
Weight |
15Kg |
-
Shanghai Yi Si Ke Mao Co., Ltd. (ES Technologies Co., Ltd.) Named in the Economic Solutions - Economical solutions, which also represents our mission: We will remain committed to laboratories around the country provide the most economical and cost-effective variety of laboratory equipment and various supplies in food safety , pharmaceutical analysis , environmental testing , petrochemical , life sciences and other fields, we offer scientists the best and most efficient service , in industry enjoyed a good reputation.
After years of developments, we have become the domestic and foreign brands in the domestic distributor or an agent . We also , work with many domestic universities, research institutes , pharmaceutical, food companies have maintained good relations of cooperation .
We present the main agent of the brand Holland Sentron PH meter, Shanghai Sunny Hengping Japan Shodex, USA Agilent, USA Waters, Shimadzu , Japan's Sumitomo, Germany, Solutions and Tools GmbH chiral GC column , Shiseido column Thermo , GE, IDEX, Agela Technlogies, Beijing Tong Heng and other innovative products .
