Mico-Spectrophotometer
Mico-Spectrophotometer
Place of Origin:
China
Brand:
Allsheng
Model:
Nano-300
Price:
Hits:
2793
Updated:
4/16/2021
  • Product Detail
  • Company Profile



    Product infotmation:

      The Nano-300 is an advanced model of Micro UV VIS Spectrophotometer based on Nano-100, with full range of wavelength (200-800nm). It is with an added new function of bacterium cell concentration measurement (OD600) in a cuvette. The Nano-300 only requires 0.5-2ul sample to measure nucleic acids, protein as quickly like Nano-100 do. Nano-300 come with a 7 inch touch screen and integranted Android operating system, with no computer required. It is an ideal equipment for a biology laboratory to make life science research more efficient.

    Adding sample     Measuring sample    quick and easy cleaning

    Features:

    1. 7 inch touch screen with simple interface. No computer required

    2. Android operating system with free software update

    3. Only require 0.5-2ul sample to perform accurate measurements.

    4. Long life’s Xenon flash lamp for up to 10 years

    5. Flexible data output. The data can be printed with built-in printer, and output via USB memory stick

    6. OD600 measurement, ideal for bacterial concentration measurement

    7. Direct micro-volume measurement with 0.5-2ul of sample. Eliminates the need for expensive accessories.

    8. Wide range of wavelength (200-800nm)

    9. Turn on and instantly measure without lamp warm up time; Full scan capability from 200-800nm with 6 sec.

    10. Switch off automatically when the machine is idle for more than 5mins, and awake by touching the screen.

    Technical Data

    Model  Nano-300
     Wavelength Range  200~800nm
     Sample Size  0.5~2.0ul
     Path Length  0.2mm (For high concentration measwrement)
     1.0mm (Ordinary concentration)
     Light Source  Xenon flash lamp
     Detector Type  3864-element linear silicon CCD array
     Wavelength Accuracy  1nm
     Spectral Resolution  ≤3nm (FWHM at Hg 546nm)
     Absorbance Precision  0.003Abs
     Absorbance Accuracy  1% (7.332Abs at 260nm)
     Absorbance Range  0.02 - 100A
     Detection Range  10~5000ng/ul (dsDNA)
     Measurement Time  <6s
     Dimensions (W x D x H)mm  210 x 268 x 181
     Data Output  USB, SD-RAM Card
     Weight  2.8kg
     Sample Pedestal Material  Aluminum alloy and Quartz fiber
     Operating Voltage  24VDC
     Operating Power Consumption  40W
     Standby Power Consumption  5W
     Software Compatibility  Android System
     OD600nm Measurement:
     Light Source  LED
     Wavelength Range  600±8nm
     Abosorbance Range  0~4A




    Code                         Description
    AS-11020-00             Nano-300  Micro-Spectrophotometer DC24V  5W
