Applications

Refrigerated Heating Lab Thermostat Shaker Incubator  ST-203R (heating and refrigeration) is widely used in germ culture, ferment, hybridization, and research of biochemical reaction, enzyme and cellular tissue and all those require high temperature and oscillation frequency. It has a wide and important range of application in research of medicine, biology, numerator, pharmacy, food and environmental protection.

 Main Features

• Refrigerated Heating Lab Thermostat Shaker Incubator

• Powder-coated steel construction with LCD display of set and working parameters.

• Stainless steel chamber with illumination. Large toughened glass window to view temperature, speed and time.

• Constant temperature and refrigeration are optional

• P.I.D environmental scanning micro-processing controller with acoustic & visual alarm

• 8-segment programs allows settings of different temperature/speed and time for each program

• Single-shaft drive technology, quite and durable

• Speed range extensible to 30-300rpm.

• High-precision frequency control system with accuracy ±1rpm

• CFC-free refrigeration system

• Independent electricity leakage and over load protection without disrupting other equipments

• High/low limit over temperature acoustic & visual alarm, high/low limit over speed alarm, stop-running protection for door opening, electric current leakage and over load protection. Motor over-heat protection.

• Automatic power cut-off in case of temperature out of control or abnormal over-temperature

• Repeat, increment (step) and 8-segment curve programming setting

• Speed saving, power-failure recovery, parameter memory, temperature/speed calibration, time display, and room/working temperature display.

• Slow-start circuit to prevent sudden start and liquid splash so as to ensure reagent safety

• 120W AC inductive long-life brushless motor, with wide speed regulation, constant torque, constant speed of rotation, and maintenance-free

• Safety protection of automatic stop of shaking when door is opened

• Standard accessory:

  Fluorescent lamp UV lamp, shaking tray (1PC), wire shelf (1PC) flask clamp (refer to Configuration)

Specifications
