CSJM-D Series Ultrapure Water System
CSJM-D Series Ultrapure Water System
Place of Origin:
China
Brand:
Haier BioMedical
Model:
CSJM-D/DUF/DUV/DUVF
Price:
Hits:
1403
Updated:
9/18/2021
  • Product Detail
  • Company Profile

    1, Specification



    Model Features

    Standard

    Model

    CSJM-D

    Feed water requirements*

    Reverse Osmosis purified water, distilled water or deionized water, 5-45 °C, 1 atm

    Process Flow**

    AC+DI+TF

    Resistivity

    18.2 mΩ•cm (25°C)

    Heavy Metal Ions

    <0.1 ppb

    Total organic carbon

    <10 ppb

    Bacteria

    <0.1 cfu/ml

    Pyrogen(Endotoxin)

    N/A

    Particulates (>0.2μm)

    <1/ml

    RNases

    N/A

    DNases

    N/A

    Resistivity

    ≥5 mΩ•cm

    Water production rate (25°C) ***

    Up to 2.0 L/min

    Water Outlets

    Two: Deionized water, and Ultrapure water

    Dimensions

    W*D*H: 500*360*540 mm, 20 kg

    Power supply/Power

    220V/50Hz, 120W

    Standard system configuration

    Water Purification Unit, accessories



    Model Features

    Pyrogen-removal

    Model

    CSJM-DUF

    Feed water requirements*

    Reverse Osmosis purified water, distilled water or deionized water, 5-45 °C, 1 atm

    Process Flow**

    AC+DI+UF+TF

    Resistivity

    18.2 mΩ•cm (25°C)

    Heavy Metal Ions

    <0.1 ppb

    Total organic carbon

    <10 ppb

    Bacteria

    <0.1 cfu/ml

    Pyrogen(Endotoxin)

    <0.001 Eu/ml

    Particulates (>0.2μm)

    <1/ml

    RNases

    <0.01 ng/ml

    DNases

    <4 pg/μl

    Resistivity

    ≥5 mΩ•cm

    Water production rate (25°C) ***

    Up to 2.0 L/min

    Water Outlets

    Two: Deionized water, and Ultra-pure water

    Dimensions

    W*D*H: 500*360*540 mm, 20 kg

    Power supply/Power

    220V/50Hz, 120W

    Standard system configuration

    Water Purification Unit, accessories



    Model Features

    Low Levels of Organics

    Model

    CSJM-DUV

    Feed water requirements*

    Reverse Osmosis purified water, distilled water or deionized water, 5-45 °C, 1 atm

    Process Flow**

    UV+AC+DI+TF

    Resistivity

    18.2 mΩ•cm (25°C)

    Heavy Metal Ions

    <0.1 ppb

    Total organic carbon

    <3 ppb

    Bacteria

    <0.1 cfu/ml

    Pyrogen(Endotoxin)

    N/A

    Particulates (>0.2μm)

    <1/ml

    RNases

    N/A

    DNases

    N/A

    Resistivity

    ≥5 mΩ•cm

    Water production rate (25°C) ***

    Up to 2.0 L/min

    Water Outlets

    Two: Deionized water, and Ultrapure water

    Dimensions

    W*D*H: 500*360*540 mm, 20 kg

    Power supply/Power

    220V/50Hz, 120W

    Standard system configuration

    Water Purification Unit, accessories



    Model Features

    Hybird

    Model

    CSJM-DUVF

    Feed water requirements*

    Reverse Osmosis purified water, distilled water or deionized water, 5-45 °C, 1 atm

    Process Flow**

    UV+AC+DI+UF+TF

    Resistivity

    18.2 mΩ•cm (25°C)

    Heavy Metal Ions

    <0.1 ppb

    Total organic carbon

    <3 ppb

    Bacteria

    <0.1 cfu/ml

    Pyrogen(Endotoxin)

    <0.001 Eu/ml

    Particulates (>0.2μm)

    <1/ml

    RNases

    <0.01 ng/ml

    DNases

    <4 pg/μl

    Resistivity

    ≥5 mΩ•cm

    Water production rate (25°C) ***

    Up to 2.0 L/min

    Water Outlets

    Two: Deionized water, and Ultrapure water

    Dimensions

    W*D*H: 500*360*540 mm, 20 kg

    Power supply/Power

    220V/50Hz, 120W

    Standard system configuration

    Water Purification Unit, accessories



    2, Features



    Fed purified water,dispense up to 2 liters of 18.2 mΩ.cm Type 1 water per minute.Pretreated source water enables more stable ultra-pure water minute.Pretreated source water enables more stable ultra-pure water Type 1 water.Suitable for critical laboratory applications



    Applications

    1) HPLC/GC-MS/ICP-AES

    2) Electrochemical

    3) Molecular Biology, Microbiology

    4) Preparation of cells and culture media

    5) ICP-MS/AAS/GF-AAS

    6) Mammalian Cell culture

    7) PCR applications and analyses

    8) Monoclonal Antibody Production

    9) TOC analyses,IC

    10) DNA sequence analysis

    11) Electrophoresis,gel analysis

    12)Ultra-trace,trace mineral,trace organics analysis
