Vacuum Freeze Dryer/Laboratory lyophilizer
Main features
CFC Free refrigeration
LCD display drying curves,English interface
Big openning of condenser, condenser has pre-freezing function
Low noise compressor, good efficiency,long service life
Condenser and operation panel are all stainless steel
Drying Chamber with organic glass is safe and visible
Shelf and tray are stainless steel, tray spacing can be customized
Small volume , easy and convenient operation
Nitrogen valve is optional
Eutectic point test device is optional
Communication interface is optional
Cascade refrigeration is optional , applied for -80℃ device
Technical parameter
Freeze drying area: 0.12㎡
Condenser capacity: 3-4L/24h
Condenser temperature: -55℃(-80 ℃ optional)
Vacuum degree: <10 Pa
Material tray: Ф200mm , 4 layers
Bulk capacity: 1.2L, 10mm thickness
Vial capacity Φ12mm: 920pcs
Vial capacity Φ16mm: 480pcs
Vial capacity Φ22mm: 260pcs
Manifold: with 8 ports
Flask: 1000ml,500ml ,250ml ,100ml
Cooling: Air，draughty , ambient temperature≤25℃
Voltage: 220V ,50 Hz; 110V, 50Hz; 110V, 60Hz
Power: 700W
Dimension: 460×625×(370+465)mm
Host weight: 41kg
-
Shanghai Leewen Scientific Instrument Co.,Ltd. is one of leading professional manufacturing enterprises of low-temperature laboratory equipment and ultrasonic equipment, Photochemical products and other lab testing machine in china.
Our company’s main products are grouped in 6 series:
Photocatalytic Reactors
Spray Dryer| Freeze Dryer
Ultrasonic Instruments
Low Temperature Water Bath
Shaker|Oscillator
Lab General Instruments
Through all our staffs joint efforts ,our main products are exported to Southeast Asia, The Middle East, Africa, Europe and The United states, and other countries and regions, now we are looking forward to cooperating with you and create a new future together.
