UV-5100 Spectrophotometer
UV-5100 Spectrophotometer
Place of Origin:
China
Model:
UV-5100
Price:
Hits:
1355
Updated:
3/8/2021
  • Product Detail
  • Company Profile

    UV-5100 Spectrophotometer



    Features

    2.5 ' LCD screen

    Equipped with a 2.5 LCD screen to give a clear display of standard curves and groups of results.

    Standard curve

    Can set up various standard curves according to customer 's solutions and find the concentrition of unknown solutions.

    Imported deuterium lamp

    UV-5100 is equipped with imported deuterium lamp which ensures low stray light,photometeric accuracy and is easy to be replaced.

    Date output

    Equipped with USB port to connected with a PC to display spectrum scanning,kinetics and multiwavelength testing results on the screen.The software is optional

    Multiple resules readout

    Can display wavelength,absorption and transmittance with 5 results per screen.It also has a memory store of up to 200 results.

    Auto setting wavelength

    Users set wavelength automatically through arrow keys to avoid operation errors.



    Technical Specification

     Model

     UV-5100

     Optical System

    Single beam, Grating 1200 lines/mm

     Wavelength Range

    190-1000nm

     Bandwidth

    4nm

     Wavelength Accuracy

    ±1nm

     Wavelength Repeatability

    0.5nm

     Wavelength Setting

    Auto

     Photometric Accuracy

    ±0.5%T

     Photometric Repeatability

    0.3%T

     Photometric Range

    -0.3-3A

    0-200%T

    Photometric  Mode

    T,A,C,F

     Stray Light

    ≤0.2%T

     Stability

    ± 0.002A/h @ 500nm

     Display

    128*64  LCD

     Detector

    Silicon Photodiode

     Light Source

    Tungsten  Lamp&D2 Lamp

     Output

    USB Port & Parallel Port(Printer)

     Power Requirements

    AC 85~250V

     Dimension

    420*280*180mm

     Weight

    12kg
