GL-21MC Blood Bank Refrigerated CentrifugeAdvanced Technique,Superior Quality

     microprocessor-controlled,inverter moror driven
     programmable RCF and speed even when it is running always able to check the speed and RCF
     two circuits for fast refrigeration and fast heating,perfect for platelet separation and radioimmunological separation
     wide power range to meet the requirements of different users

The imported refrigerated system without Freon(R404a Refrigerant) for the purpose of environment protection
Simple Operation,Best Effect
Intellectual interface, touch-pad surface board

     programmable procedures for both save and extract
     10 levels of speed for best centrifugation
Various Protections for Safety and Reliability
     allowing ultra-speed and ultra-temperature, without balance, overcurrent, overvoltage and other protections, with10 self-diagnoses to ensure safety

Stainelss steel chamber,3 tier safety protection steel cover ,electronic and mechanic door interlock for safe operation

Technical Data

Max Speed	21000r/min
Max RCF	47400×g
Max Capacity	6×500ml
Temperature Accuracy	±1^oC
speed accuracy	±50r/min
Temp Range	-20^oC+40^oC
Timer Range	0~9H59min
Noise	≤65dB(A)
Power	AC220V 50HZ 30A
Dimensions	600×640×800(L×W×H)mm
Weight	380kg

Rotors:

Rotor No.	Rotor	Max. Speed(r/min)	Max. RCF(x g)	Capacity
No.1	Angle Rotor	21000	47400	16 x 10ml
No.2	Angle Rotor	16500	31100	12 x 20ml
No.3	Angle Rotor	20000	43000	16 x 10ml
No.4	Angle Rotor	15000	27210	8 x 50ml
No.5	Angle Rotor	15000	25700	6 x 70ml
No.6	Angle Rotor	12000	19800	8 x 100ml
No.9	Angle Rotor	14000	27610	4 x 300ml
No.10	Angle Rotor	12000	22470	6 x 300ml
No.11	Angle Rotor	20000	43000	6 x 50ml
No.17	Angle Rotor	9000	14400	6 x 500ml
No.32	Angle Rotor	20000	43000	32 x 1.5ml
No.15	Continuous Flow Rotor	14000	21290	1000ml
No.18	Continuous Flow Rotor	8000	9530	3000ml

CHANGSHA PINGFAN INSTRUMENT AND METER CO., LTD, located at Changsha Wangchengpo Development Area, is a high-tech stock company modified from a state-run large-scale enterprise. It is the first enterprise of the same trade to get a certificate from China Quality Certification Center. With a history of nearly 30 years' professional design and manufacture of centrifugal machinery, Foreign trade sales have breakthrough million ，our company has accumulated rich assets for research and development with constant introduction and absorption of the latest techniques both home and abroad. Our company is the first to launch the new models of intelligent centrifuges, autobalancing centrifuges, super-capacity centrifuges, milk centrifuges, microspin filtering centrifuges, and blood thaw machinery. Our products are extensively applied in high education, agriculture, biochemical research, biochemical test, blood stations and blood banks, bioproducts, life science, genetic engineering, radioimmunology, environment protection, safe food, penal investigation and other fields. Our centrifuges are characterized by brushless motors with capacity of frequency conversion, inkling control by computers, users-friendly design of press buttons, and special combinations to reduce vibration. Every functional index of our products has reached the leading level of our country.
