DD8KR Large Capacity Refrigerated Centrifuge
Features:
1. Programmable microprocessor control( AC brushless motor) with touching panel, LCD&LED display of speed, RCF, time and temperature and all running parameters.
2. CFC-free refrigeration, small vibration, low noise.
3. High-quality steel, stainless steel centrifugal chamber.
4. Functions: RCF selection, quick run, automatic rotor recognition, electronic imbalance detection, dynamic electric brake system, conversion of RPM/RCF.
5. Procedures of adjustable rise-and- fall speed from grad 0 to 9 and 40 kinds of self-defining models. Fast accel and decal profile.
6. Lid lock and interlock safety provision. Auto lock rotor system.
7. Alarm: lid open, imbalance, over speed, rotor mounting abnormally.
Technology Parameters:
|
Model Number
|
DD8KR Large Capacity Refrigerated Centrifuge
|
|
Display
|
LCD/LED
|
|
Max Speed
|
7200rpm
|
|
Speed Accuracy
|
±20rpm
|
|
Max RCF
|
12160×g
|
|
Max Capacity
|
6×2400ml
|
|
Tem range
|
－20～40℃
|
|
Tem accuracy
|
±1℃
|
|
Timer
|
0～99h59min59s
|
|
Noise
|
≤65dB
|
|
Power supply
|
AC220V，50Hz，4.75KW，35A
|
|
Inner Material
|
Stainless Steel
|
|
Outer Material
|
High-quality Steel
|
|
Dimention
|
960×860×1200mm
|
|
Weight
|
500kg
|
Rotor:
|
NO
|
Rotor
|
Max speed
|
Max RCF
|
Capacity
|
Tube（mm）
|
|
NO.1
|
Angle Rotor
|
7200rpm
|
12160×g
|
6×1000ml
|
Φ97×175
|
|
NO.2
|
Angle Rotor
|
4500rpm
|
7000×g
|
6×2400ml
|
|
|
NO.3
|
Swing rotor
|
4000rpm
|
5000×g
|
6×2×1000ml
|
|
|
NO.4
|
Swing rotor
|
8000rpm
|
11680xg
|
6x500ml
|
|
