Cold Trap

CHARACTERISTICS OF USES：

Capture water vapor and harmful gases emitted from vacuum drying oven or decompression concentration plant. Improve the service efficiency of the vacuum system, substantially , reduce the amount of steam inhalation of vacuum pump and extend the service life of the vacuum pump.

●The showing of cold trap temperature is useful for controlling the opening time of the vacuum pump and preventing piping of water being pumped into the pump.

●The cold trap slot adopts stainless steel SUS 304, which can be used for experiments of water system and ethanol system. Equipped with glass condenser, it can be applied in the experiments of acid system and organic solvent system

●It can be used as pre-freeze tank and low-temperature trough.

●Equipped with drain valve for easy drainage.

Precooling Rotary instrument

Slewing arrangement of flask for pre-cooling. When rotating, the solution is condensed into filmily on the wall, which can shorten the drying time.

■ Rotary speed：30～180 rpm

■ Available equipment models: all low-temperature cooling liquid circulating pumps

Technical data：

Model	CT-2000H	CT-2000L	CT-5000H	CT-5000L
Cold trap mode	Cooling directly dependent on barrel		Cavity cooling (glass condenser: matching,Direct freezing trap)
Dehumidification volume	Max.1kg（Water）		Max.4kg（Water）
Min. Temperature	-40℃	-80℃	-40℃	-80℃
Temperature digital	Digital display
Bath materials	Stainless Steel SUS 304
Interior size（mm）	200×200		250×250
Ambient temperature (℃)	5～25
Power Supply（V/Hz）	220/50

Zhengzhou Sykes Biotechnology Co., Ltd., a professional manufacturer of laboratory instruments, is a technological innovative enterprise integrated with researching, developing, manufacturing and sales. Professional R&D team always provides customers with perfect solutions. Products are widely used in chemical, biological, pharmaceutical industries, new materials, new energy, electronics, metallurgy, petroleum, mechanics and other fields. Main products include rotary evaporator, glass reactor, short path distillation system, vacuum pump, recirculating chiller, hermetic refrigerated and heating circulator, thermostatic bath circulator, heating bath circulator, magnetic stirrer, electric heating mantle, etc. Zhengzhou Sykes always speaks with strength and high-quality products. Our products have been exported to North America, Europe, Asia and other regions. With a professional R&D team, high quality products, competitive price, we believe that we are your best choice. Looking forward to build a long-term cooperative relationship with customers worldwide.
