Peristaltic Pump WG600S+YZ35(PPS/Easy-load head)Flow range:400-26000mL/min
Peristaltic Pump WG600S+YZ35(PPS/Easy-load head)Flow range:400-26000mL/min
Place of Origin:
China
Brand:
Lead Fluid
Model:
WG600S+YZ35 PPS pump head industrial variable speed peristaltic pump
Price:
$1200-$1700
Hits:
2471
Updated:
5/12/2021
  • Product Detail
  • Company Profile
    Product introduction
    The pump is suitable for transferring large amount of fluid in industry. One channel flow range: 0.4-13 L/min, speed range: 30-600 rpm. It can cascade two pump heads. It adopts the brushless motor drive with large torque, free maintenance. Having basic functions:such as reversible direction, start/stop, full speed (fast cleaning) and speed-variable. RS485 interface, as adopting the MODBUS communication protocol, the pump is easier to be connected with other equipments, such as computer, human machine interface and PLC.

    » Function and Feature
    • Stainless steel housing.
    • keypad controls running speed, reversible direction, start/stop, full speed, easy operation.
    • Applicable pump head: YZ35, 2xYZ35.
    • One channel flow range: 0.4-13(L/min).
    • Speed resolution: 1rpm.
    • Four-figure digital LED indicator displays working speed.
    • Brushless motor drive, free maintenance.
    • Stainless steel housing, easy to clean, excellent resistance to the corrosion of the acid,alkali,sodium and the
      organic solvents.
    • The circuit board with conformal coating makes it dust-proof and moisture-proof.
    • External high-low electrical level controls the start/stop, reversible direction and easy dispensing function,
      optically coupled isolator, can choose 5V,12V,24V. External analog adjusts the rotate speed, can choose 0-
      5V/10V, 4-20mA.
    •RS485 interface, MODBUS protocol is available, easy to connect other equipments.

    » Technical parameters
    • One channel flow range :0.4-13L/min
    • Flow accuracy:<3%
    • Speed range:30-600rpm.
    • Speed resolution: 1 rpm
    • Power supply :AC 220V±10%,50Hz/60Hz(standard),
    • Power consumption:<300W
    • External control:Input electrical level 5V, 12V (standard),24V(optional).
    • External communication interface:RS485 communication interface,
    support the MODBUS protocol.
    • Ambient temperature:0 ~ 40℃
    • Relative humidity:<80%
    • IP grade:IP31
    • Dimensions(LxWxH)340mmx235mmx175mm
    • Weight:13KG
    peristaltic pump head and tubing matching information

    » WG600S Pictures of applicable pump head

             WG600S(YZ35)          WG600S(2×YZ35)

    » WT600S Applicable pump head and tubing, flow parameters

    Drive type

    Pump head

    Channel number

    Tubing(mm)

    One channel flow rate
    (L/min)

    WG600S
    (304SS)

    YZ35

    1

    73#,82#

    0.4~13

    2*YZ35

    2

    73#,82#

    0.4~13


    » Specifications
