Features
- In accordance with international standard ASTMD523, ASTMD1455, ASTMC346, ASTMC584, ASTMD2457, DIN ENISO2813, DIN67530, ENISO7668, JISZ8741, MFT30064, TAPPIT480, GB9754, GB/T13891, GB7706 and GB8807. Its technical parameters conform with JJG696-2002.
- Accurate measurement, good repetitveness.
- Small in size, easy to carry.
- Auto calibration.
- Intelligent design, rapid measurement.
- Able to store 254 groups of measurements.
- Built-in lithium ion rechargeable battery.
- Backlight display, suitable for low light environment.
- Use USB/RS-232 data output to connect with PC.
- Provide Bluetooth data output choice.
Material And Angle Selection Recommended
* 20°: High gloss paint, printing ink, plastics, paper and other materials.
* 60°: Middle gloss paint, printing ink, plastics, ceramics, marble and other materials.
* 85°: Low gloss paint, camouflage coatings materials.
Specifications
|
Display
|
4 Digits Backlit LCD
|
|
Measuring Angle
|
60º
|
|
Range
|
0.1GU~200 GU
|
|
Gloss Units
|
GU
|
|
Accuracy
|
±1.0GU
|
|
Resoltuion
|
0.1
|
|
Repeatability
|
±0.5GU
|
|
Measuring Area
|
7mmx14mm（Ellipse）
|
|
Data Memorized
|
254 Groups
|
|
Operating Conditions
|
Temp:0ºC ~40ºC Humidity:<85%RH
|
|
Power Supply
|
3.7V Lithium Ion Rechargeable Battery
|
|
Dimensions
|
140mmx45mmx75mm
|
|
Weight
|
305g(Including Batteries)
|
|
Stabdard Accessories
|
Main Unit
|
|
Holder with Calibration Standard
|
|
Optical Cleaning Cloth
|
|
Carrying Case
|
|
Operation Manual
|
