Product Description

Specification

BIOBASE Clinical Auto Chemistry Analyzer

Overall Performance	Model	BK-200
	Throughput	200 Tests/hour
	Analysis Method	End-point, Fixed-time, Rate(Kinetic)
Sample & Reagent System	Sample Positions	37 sample positions
	Reagent Position	28 reagent positions
	Sample Volume	2~70ul
	Reagent Volume	20~350ul
	Probe	Liquid level sensor function, anti-collision function.
	Probe Washing	Automatic washing interior and exterior
	Reagent Cooling	Refrigerated tray with independent switch
Reaction System	Temperature Control	37+0.1℃, real-time monitoring
	Cuvettes	48 reusable cuvettes,optical length 6mm
	Mixer Probe	Independent stirring
	Washing	Automatic cuvettes washing
	STAT function	YES
Optical System	Light Source	6V/10W halogen lamp
	Spectrophotometry	Post-spectral spectrophotometry
	Wavelength	340,405,450,510,546,578,630,700nm
	Absorbance	0~3.0Abs
Calibration & QC	Calibration	Linear:K factor, 1-point ,2-point and multipoint liner Non-Linear:Spline,Polygon,Index,Ogarithm,Logit-4P, Logit-5P
Calibration & QC	Quality Control	Real-time QC, Westgard multi rule, Cumulative Sum Check,Twin Plot(2D)
Data Management	Software	Windows 7/8/10 , 32or 64bit
	LIS System	Bi-direction,support HL7 protocol
	Interface	LAN port access
	Printer	External,multiple reporting mode available
Working Conditions	Power Supply	AC220V+10%,50/60Hz, 110V+10%,60Hz, 300W
	Temperature	10℃~30℃
	Water Consumption	Deionized water:3L/H
	Humidity	30-80%
Size & Weight	Size (WDH)	625425460mm
	Net Weight	36kg
	Package Size (WDH)	721531855mm
	Gross Weight	50kg

Do you have any questions about these parameters? please feel free to contact me~

Features

Features:

37 Sample positions.

28 Reagent positions.

48 Reaction cuvettes.

200 tests per hour.

Probe anti-collision function.
