•Use liquid nitrogen for deep and low temperature preservation.
•The activity of biological samples can be maintained for a very long time.
•Provide complete automation solutions.
•Avoid the inefficiencies and pitfalls of manually conducting sample storage and management.

The model is engineered by following innovative designs:

using one large capacity freezer with creative comb design can maximum storage capacity;

using full automatic operation mechanism design with a five-shaft automatic structure, can ensure a higher efficiency and more reliable operation.;

advanced automatic lid opening design can lead to faster operation;

vacuum and negative pressure sample pick-up mechanism design can secure more reliable operation and more convenient maintenance;

high dryness dehumidification system can prevent frost in working area and frozen inside the storage area;

special cryogenic protection pick-up device can ensure the little exposure of frozen sample;

integrated two-dimensional code scanning system can realize high efficient sample information verification;

comprehensive automatic transfer window design with the functions of automatic dehumidifying and automatic import and export can easily equip with advanced AGV system;

installed with UPS can ensure uninterrupted operation;

introducing server to store the information can ensure more reliable and safety data storage;

the intelligent BSN-Cyber operation system can be easy to use on both single and multiple modular;

embedded touch screen with obliquity display can have more convenient conversational interface;

comprehensive system design for information feedback and abnormal alarm ensure all kinds of abnormal situation will not affect the safety of the sample;

easy removable module design can realize emergency rapid transfer of samples.

Specification:

Item	Specification
Model	BSN-400
Storage Capacity	40000（2.0ml Vials）
Dimension (mm)	1500×2400×2450mm（Width×Depth×Height）
Weight (empty)	2500KG
Weight (full capacity)	2800KG
Power	Standby：＜500w，Max operating power：＜2500w
Voltage	220V，50Hz
Hose Interface (mm)	Ø15mm
Touch Screen	15 Inch
LN2 Evaporation Rate (L/day)	20（Static）
Freezer hold time（≤130℃）	≥48h
Storage Temperature	≤-160℃
Freezer Dimension (mm)	Φ1000x1650mm
