Model
|
DH45L
|
DH65L
|
DH125L
|
DH210L
|
|
Cycle Mode
|
Breeze circulation
|
|
Function
|
Tem. Range
|
RT+5-65℃
|
|
Tem. Resolution Ratio
|
0.1℃
|
|
Tem. Motion
|
±0.5℃
|
|
Tem. Uniformity
|
±0.8℃
|
|
Structure
|
Inner Chamber
|
Mirror stainless steel
|
|
Outer Shell
|
Cold rolling steel electrostatic spraying exterior
|
|
Insulation layer
|
Polyurethane
|
|
Heater
|
Mica electrothermal film
|
|
Power Rating
|
0.35kW
|
0.45kW
|
0.6kW
|
0.7kW
|
|
Exhaust hole
|
φ28mm top(with function of test hole)
|
|
Controller
|
Tem. control mode
|
PID Intelligent
|
|
Tem. setting mode
|
Touch button setting
|
|
Tem. display mode
|
Measuring temperature: LCD upper row; Setting temperature: the lower row
|
|
Timer
|
0-9999 min (with timing wait function)
|
|
Operation function
|
Fixed temperature operation, timing function, auto stop.
|
|
Additional funciton
|
Breeze circle fan,LED Floodlight, UV lamp ,Sensor deviation correction, temperature overshoot self-tuning, power-off parameter memory
|
|
Sensor
|
PT100
|
|
Safety device
|
Mechanical independent temperature limiter, over temperature sound-light alarm
|
|
Specification
|
Inner Chamber size(W*L*H)(mm)
|
350*350*350
|
400*350*450
|
500*450*550
|
600*580*600
|
|
Exterior size (W*L*H)(mm)
|
525*480*620
|
575*480*720
|
675*580*820
|
775*710*870
|
|
Packing size (W*L*H)(mm)
|
605*572*775
|
655*572*875
|
755*672*975
|
855*802*1025
|
|
Volume
|
45L
|
65L
|
125L
|
210L
|
|
Shelf number
|
7
|
9
|
13
|
14
|
|
Load per rack
|
15kg
|
|
Shelf space
|
35mm
|
|
Supply(50/60HZ)Current rating
|
AC220V/1.1A
|
AC220V/1.1A
|
AC220V/2.3A
|
AC220V/2.7A
|
|
NW/GW (kg）
|
27/30
|
32/35
|
45/49
|
58/63
|
|
Accessory
|
Shelf
|
2
|
|
Shelf frame
|
4
|
|
optional accessories
|
Shelf, USB interface, printer, recorder, External Communication, remote control, wireless SMS alarm
|
