Model Number

MS-100(Heated）

MSC-100(Heating and cooling）

Temprature range

RT+5℃~100℃

0℃~100℃(RT≤20℃ )

Temprature setting

1min-100h

1min-100h

Temprature stability

±0.5℃

±0.5℃

Display precision

±0.1℃

±0.1℃

Shake speed

200~1800rpm

200~1800rpm

Shake speed

2-3mm

2-3mm

Heating time

≤15min (25 to 100℃)

≤15min (25 to 100℃)

Cooling time

NO

≤25min(20℃ to 0℃) (RT=20℃)

Size&Weight(H*W*D)

270×190×190（mm）-8kg

270×190×190（mm）-9.5kg

Power

AC220V,50Hz,200W

AC220V/120V,50/60Hz,250W

Standard module

35*2.0ml or 35*1.5ml centrifuge tube

（C or D）：35*2.0ml or 35*1.5mlcentrifuge tube

Optional module：

A,B,C,D,E,F,G,H,J,K,L,M

A,B,C,D,E,F,G,H,J,K,L,M

Programming function：

5groups

5groups

Air cooling function：

Yes

4 Type Optional Module

REMARKS

A

96*0.2ml Standard module 100℃（with hole）

B

54*0.5ml centrifuge tube 100℃

C

35*1.5ml centrifuge tube 100℃

D

35*2.0ml centrifuge tube 100℃

E

15*0.5ml+20*1.5ml centrifuge tube 100℃

F

24* ≤￠12mm tube 100℃

G

32*0.2ml+25*1.5ml  centrifuge tube 100℃

H

32*0.2ml+10*0.5ml+15*1.5ml  centrifuge tube  100℃

J

96*0.2ml microwell plate(ELISA Plate) 100℃（module plate）

K

24*5ml centrifuge tube 100℃

L

12*15ml (max  speed 600rpm) 100℃

M

6*50ml (max speed 600rpm) 100℃
