Product Description
BK6190 Auto 3 Part Hematology Analyzer
Features:
* Throughput: 60T/H
* 8 inch touch screen
8 20 parameters + 3 histograms
* 2 reagents only
* 3 counting modes
* 100,000 sample results
* Support LIS and external printer
Technical Parameters:
|
Model
|
BK-6390
|
|
Throughput
|
60 tests/hr
|
|
Assay Items
|
22 parameters, 3 parts differential of WBC
|
|
Measuring Principle
|
Impedance for cell counting Cyanide-free method for HGB
|
|
Parameters
|
WBC, Neu#, Lym#, Mid#, Neu%,Lym%, Mid%, RBC, HGB, HCT, MCV, MCH, MCHC,RDW-SD, RDW-CV, PLT, MPV, PDW, PCT, P-LCR
|
|
Histograms
|
HistogrWBC, RBC, PLT histogram
|
|
Sample Volume
|
Normal:10μL ;Predileted:20μL
|
|
Calibration
|
Manual&auto calibration
|
|
Counting Modes
|
Venous, capilary, prediluted
|
|
Printer
|
Built-in thermal printer,USB to external printer(optional)
|
|
Language
|
English, Spanish, Italian, Portuguese, French etc
|
|
Data Input
|
8 inch touch screen, keyboard, mouse
|
|
Output
|
RS232 port, USB port, VGA port. LIS system avaliable
|
|
Storage
|
100,000 results with histogram
|
|
Carry-over rate
|
Parameter
|
CV
|
|
WBC
|
≤ 2%
|
|
RBC
|
≤ 1%
|
|
HGB
|
≤ 2%
|
|
PLT
|
≤ 2%
|
|
Background
|
Parameter
|
Background
|
|
WBC
|
≤ 0.2×109/L
|
|
RBC
|
≤ 0.02×1012/L
|
|
HGB
|
≤ 1 g/L
|
|
HCT
|
≤ 0.5%
|
|
PLT
|
≤ 10×109/L
|
|
Precision
|
Parameter
|
CV
|
Measurement range
|
|
WBC
|
≤ 2.0%
|
(4.0-15.0×109)/L
|
|
RBC
|
≤ 1.9%
|
(3.5-6.0×1012)/L
|
|
HGB
|
≤ 1.9%
|
(110.0-180.0g)/L
|
|
MCV
|
≤ 0.4%
|
(80.0-110.0)fL
|
|
PLT
|
≤ 4.0%
|
(100.0-500.0×109)/L
|
|
Linearity
|
Parameter
|
Measurement range
|
CV
|
|
WBC
|
(0-5.9×109)/L
(6.0-99.9×109)/L
|
(±0.3×109)/L
±5%
|
|
RBC
|
(0-0.99×1012)/L
(1.0-9.99×1012)/L
|
(±0.05×1012)/L
±5%
|
|
HGB
|
(0-99.0g)/L
(100.0-300.0g)/L
|
(±2.0g)/L
±2%
|
|
PLT
|
(0-99×109)/L
100-999×109)/L
|
(±8.0×109)/L
±10%
|
|
Power supply
|
AC 100/220±10%,60/50Hz
|
|
Package Size
|
580*470*590mm
|
|
Gross Weight
|
26.6kg
|
