Applications:
Used to measure rotative velocity, surface speed, frequency of motor. Applicable to the product departments of motor, fan, paper-product, chemical fiber, washing-machine, automobile, airplane, steamer etc.
* Multifunctional, one instrument combines PHOTO TACH.(RPM) & CONTACT TACH. (RPM , m / min, ft / min ). It can also be applied to the measurement of Frequency, Cycle, Pulse Times, Pulse Distance, User-defined Pulse Distance, etc.
* Digital display with no guessing errors.
* Wide measuring range and high resolution.
* The last value / max. value / min. value will be automatically stored in memory.
* The use of durable, long-lasting components, including a strong, light weight ABS-plastic housing assures elegant shape and ease of use.
* Use USB data out put and RS- 232 data out put to connect with PC.
* Provide Bluetooth data out put choice.
Measuring Range
Laser:2.5 ~ 99,999 r / min
Contact: 0.5 ~ 19,999 r / min
Surface Speed: 0.05 ~ 1999.9 m / min 0.2 ~ 6560 ft / min
Frequency : 0.04~1666.65 Hz
Resolution:
Rotative Velocity:
0.1 r / min (0.5 ~ 999.9 r / min)
1 r / min (Over 1000 r / min )
Surface Speed:
0.01 m / min (0.05 ~ 99.9 m / min)
1 m / min (Over 100 m / min )
Or 0.1 ft / min (0.1 ~ 999.9 ft / min)
1 ft / min (Over 1000 ft / min )
Accuracy: ± (0.05% n + 1 d)
Sampling Time: 1.0 s (Over 60 r / min )
Test Range Select: Automation
Memory: Max / Min / Last Value
Time Base :Quartz Crystal
Laser Tach Detecting Distance:
50 ~ 250 mm / 2 ~ 10 inch (Typical), Max. 600 mm / 24 inch
Power Consumption:80 mA (Testing)
Operating Temperature: 0 ~ 50 °C (32 ~ 122°F)
Power Supply : 4 x 1.5 V AAA size (UM-4) battery
Dimensions
Main Unit :140 x 72 x 34 mm ( 5.5 x 2.8 x 1.3 inch)
Sensor : Φ 45 x 195 mm ( Φ1.8 x 7.7 inch)
Weight: 245 g / 0.540 lb (Not Including Batteries)
Standard Accessories :
1. Main Unit
2. Sensor
3. Carrying Case
4. Operation manual
5. Reflective tape 350mm
6. Cone Adapter(AS35A)
7. Funnel Adapter(AS35B)
8. Surface speed test Wheel(AS35C)
