Model LZJ-4D ent surgery microscope
Use：
My company recently developed a portable multifunctional surgical microscope, surgical microscopes LZL-4D applicable to neurosurgery, brain surgery, ENT, ophthalmology surgery. Optical path parallel optical path with a large depth of field, vision, illumination uniformity. Optional monocular teach-mirror optical hinge, digital camera interface and CCD interface. The instrument is also an animal test, cadaver dissection and microscopic teaching ideal instrument.
Technical performance and parameters：
1.Binocular focal length: 160mm
2.Eyepiece 12.5x wide angle, with diopter adjustment and limit device
3. Working distance objective lens: F: 200,250,300,400 mm (optional complex achromatic objective lens)
4. Electric foot control focusing, fine focusing range: 40mm
5.Field of view diameter: 80mm-12.5mm
6. Mesh distance adjustment range :50-75mm
7.Primary mirror has six degrees of freedom movement, manual adjustment with ease and flexibility. Tone before and after tilting range: -5 ° to 90 ° around tune pour range: ± 30 °
8. Fifth gear; zoom ratio 1:6; magnification 4x, 6x, 10x, 16x, 24x
9.Cold light source 12V, 100W; maximum illumination of up to 80000Lx
10. pneumatic spring balanced rack, wingspan 1050mm, stepless rotating 180 °, move up and down the range of ≥ 500mm.
11. power supply voltage and frequency: 220V ± 10%, 50Hz ± 1Hz
110V ± 10%, 60Hz ± 1Hz
12. Optional optical hinges, splitter, Teach monocular microscope, digital camera interface, CCD interface and 0 ° eyepiece and a xenon lamp illumination.
