MK-VET2 Vertical Electrophoresis Cell

1.The installation of glass plates can be completed in just 15 seconds, no need for knob, fast and convenient.

2.With a gel casting in original position, no need to move glasses from gel making to electrophoresis running.
It is more convenient to observe gel preparing through both sides of the glasses.

3.With the background color, makes it easy to observe sample loading and electrophoresis running.

4.Abundant buffer not only guarantees a cooling environment, but also keeps the PH value stable
during the whole experiment.

5.Auto-switch-off when the lid is moved.

MK-VET2 Technical specifications
Glass plate area(W×L)	100×100（mm）
Gel area(W×L)	82×88（mm）
Gel thickness	0.75, 1.0, 1.5（mm）
Amount of gel	1～2(piece)
No.of samples	11～30
Buffer capacity	～750（ml）
Volume(L×W×H)	150×120×115（mm）
Weight	1.5kg

MK-VET2 Packing configuration
Parts name	Packing quantity
Body tank with electrode	1
Gel casting base	1
Notched glass plates	4
0.75mm bonded glass spacer	2
1.0mm bonded glass spacer	2
1.5mm bonded glass spacer	2
0.75mm thickness 11 wells comb	2
1.0mm thickness1 11 wells comb	2
1.5mm thickness 11 wells comb	2
0.75mm thickness 15 wells comb	2
1.0mm thickness 15 wells comb	2
1.5mm thickness 15 wells comb	2
Gel Shovel	1
Clamp version	2
Dummy plate	1
Electrical Cables	1
